Rated voltage 12 VDC
Operating voltage 6V~ 13.8 V
Rated current 0.8 А
Rated power 0.96 W
Starting voltage 6V
Limiting current 0.35 А
Insulation type UL1007
Maximum speed 8000 rpm ±10 %
Air flow 2.7 CFM (max)
Maximum static pressure rating 1.35 mm -Н20 (max)
Noise level 20dB(А)
Operating period 40 ООО hours, slider bearing. Environmental conditions: 25 °С, 65 % ± 20 % RP.
Dimensions З0хЗ0х10 mm
Blade wheel PC UL 94V-0
Framework PC UL 94V-0
Lubricant -
Ring seal Rubber ring seal
Stator Stainless steel SUS420J2
Bearing type Slider bearing х 1 / ball bearing
Silicon steel strip Н23
Integrated circuit S76A
Lead-in wire UL1007
Connector 2510 264 mm
Enamelled copper wire MW-2 UEW temperature resistance150 °С
Wiring board Microprocessor single board module 94V-0
Вес брутто(измерено в Coolera): 10 Грамм.
