•Small Footprint: 2.4" x 2.4" x 1.5"
•50,000 hours MTBF (Mean Time Between Failure) equivalent to 5 years lifetime.
•Superior 12 Volts DC convenience: plugs into the computer power supply
•The MCP355 can be used with full confidence in any MP servers, and high-end workstations
•Superior real world performance thanks to its high pressure characteristics (20ft of head). The MCP355 is particularly well adapted to the proliferation of daisy-chained liquid cooling devices in a single circuit: Multiple Processors, Chipset, Graphics, and Hard Drives
•3/8" barb fittings
•No maintenance when used with de-mineralized water, and anti-fungal additives (Our HydrX additive is recommended)
•Quick installation with adhesive neoprene pad, or permanent installation with screws and grommets
•RPM sensor plugs to 3 pin motherboard fan connectors and reports impeller rotational speed

Specifications

Nominal Voltage 12 V DC
Operating Voltage 8 to 13.2 V DC
Minimum Start-up Voltage 9 V DC
Nominal Power (@ 12 V) 14 to 19W
Nominal Current (@ 12 V) 1.16 to 1.58 A
Nominal Head Pressure (@ 12 V) 15 ft (4.5 m)
Nominal Discharge (@ 12 V) ~ 120 GPH (454 LPH)
Connection Size 3/8" barbs (10mm)
Maximum (working) Pressure 22 PSI (1.5 BAR)
Temperature Range Up to 140 °F (60 °C)
Electrical Connector Molex 4-pin
Weight 7.3 oz (207 g)
Noise Level 30 ~ 32 dBA @ 2"
Motor Electronically Commutated, Brushless
MTBF 50,000 Hours
RPM Signal Yes
RoHS Compliant
EAN13: 0877790000356
