Dimensions 177 (W) x 32.5 (H) x 110.6 (D) mm
Fan Bearing Sleeve
Fan Connector 3-Pin
Compatibility Nvidia : GTX 980, 970, 780 Ti, 780, 770, 760, Titan, 680, 670, 660Ti, 660, 580, 570, 560Ti, 560, 560SE
AMD : R9 290X*, 290*, 280X**, 280**, 270X, 270 HD7970**, 7950**, 7870, 7850, 6970, 6950, 6870, 6850, 6790, 6770, 5870, 5850, 5830
The compatibility list is based on AMD Radeon and NVIDIA"s reference board layout, screw spacing and die height only. Please check the height restriction before purchase.
* Some variation in die thickness and height may cause issues with screws being too short to install on some AMD 290-based cards.
* Do NOT force the G10 to fit if your card is too thick, contact support for a revised screw set.
** Some variations in AMD die height may require the use of a shim.
Compatibility NZXT : Kraken X61, Kraken X41, Kraken X31, Kraken X60, Kraken X40
Corsair : H105, H110, H90, H75, H55 , H50 (CW-9060006-WW only)
Antec : KUHLER H2O 920V4, KUHLER H2O 620V4, KUHLER H2O 920, KUHLER H2O 620
Thermaltake : Water 3.0 Extreme, Water 3.0 Pro, Water 3.0 Performer, Water 2.0 Extreme, Water 2.0 Pro, Water 2.0 Performer
Zalman : LQ-320, LQ-315, LQ-310
Fan Dimensions 92 (W) x 92 (H) x 25 (D) mm
Fan Input Power 2.16W
Fan Current 0.18A
Fan Speed 1500 ± 10% R.P.M.
Fan Voltage 12V DC
EAN13: 5060301691012
Вес брутто(измерено в Coolera): 380 Грамм.
