ELC-LMR240-BS
Compatible Sockets
Intel® LGA 775/1150/1151/1155/1156/1366/2011/2011-3*
AMD® AM2/AM2+/AM3/AM3+/FM1/FM2/FM2+
Cold Plate Material
Copper
Weight (without fan) 580g 740g
Thermal Grease Dow Corning® TC-5121

Pump
Bearing Type
Ceramic Bearing
MTBF (hours) 50,000
Motor Speed (RPM) 2,700
Rated Voltage (V) 12
Rated Current (A) 0.3
Connector 3 pin

Radiator
Dimensions (mm) D 120 x W 274 x H 27
Material Aluminium

Tubes
Length (mm) 300
Material Rubber (Polyamide)

Fan
Fan Dimensions (mm) W 120 x H 120 x D 25
Fan Speed (RPM) 500 - 1,200/1,600/2,000
Rated Current (A) -
Rated Voltage (V) 12
Connector 4 pin PWM
Quantity 2x
Mounting Metal Screws
Fan Model BS (Double Batwing)
Air Flow (m3/h) 47.1 - 99.1/128.3/163.1
Air Flow (CFM) 27.7 - 58.3/75.5/96.0
Static Pressure (mm-H2O) 0.4 - 1.3/2.4/3.0
Noise Level (dB(A)) 16 - 23/30/35

* except server mainboards with LGA 2011-3 socket
EAN13: 4713157721761
