Аксессуары Koolance HXP-193 Compact Plate Heat Exchanger
Описание:
Used in various industries, plate heat exchangers provide highly efficient heat transfer between two liquids without allowing them to mix. They are ideal for managing coolant pressure differences, and for isolating sensitive equipment from potentially damaging liquids. Koolance plate heat exchangers are among the most compact and cost effective available.
The HXP-193 is made of copper-brazed stainless steel and plated externally in nickel. A detachable heavy steel mounting bracket and screws are included. G 3/8 BSPP threads.
Heat Transfer: 4.0 kW (13,600 BTU/hr) (@5LPM, Delta between inlets = 20°C)
Design Pressure: 10kgf/cm2 (140 PSIG)
Design Temperature: -40°C (-40°F) min, 130°C (270°F) max
Number of Plates: 12
Channel Plate Material: SUS304 Stainless Steel
Brazing Material: Copper
Вес брутто(измерено в Coolera): 1120 Грамм.
Поделиться:
The HXP-193 is made of copper-brazed stainless steel and plated externally in nickel. A detachable heavy steel mounting bracket and screws are included. G 3/8 BSPP threads.
Heat Transfer: 4.0 kW (13,600 BTU/hr) (@5LPM, Delta between inlets = 20°C)
Design Pressure: 10kgf/cm2 (140 PSIG)
Design Temperature: -40°C (-40°F) min, 130°C (270°F) max
Number of Plates: 12
Channel Plate Material: SUS304 Stainless Steel
Brazing Material: Copper
Вес брутто(измерено в Coolera): 1120 Грамм.
Поделиться:

Производитель: Koolance
